HomeLike Premium Rigid Core 8mm 28mil SHIELD4MAX™

Through years of research and development, HomeLike grandly launched Signature 8mm 28mil Rigid Core PA collection which is designed for commercial spaces and high-end residential homes with unprecedented durability, unmatched beauty and effortless maintenance. Explore the multiple incomparable features of your life-lasting and resilient flooring choice !!

● Enhanced with proprietized & innovative SHIELD4MAX™ technology which was built in the planks with 100% waterproof, unparalleled scratch-shield, stain-shield and bacteria-shield performance.

● Luxury extra-long and ultra-wide planks with painted bevels and Embossed-In-Register technology which intensifies the depth, texture and authentic wood look of the flooring.

● Ultra thick core and exceptional dense sound pad enable the installed planks with increased sound-proof performance.

● Specially designed to endure heavy everyday foot traffic with extreme performance, HomeLike Signature PA collection suits to high-traffic commercial spaces incl. corporate offices, banks, hotels and other commercial buildings.

Specifications Technical Data
Length 60" Width 9.06"
Thickness 8.0mm Wear Layer 28mil
Finish EIR Edge Description Painted Bevel
Sqft/Box 18.87 lb/Box 48.6
Box/Plt 52 Sqft/Plt 981.24
lb/Plt 2527.2 Plt/FTL 17
Limited Residential Warranty Lifetime Limited Commercial Warranty 20 Years
No. Description Method Standard Result Performace
Rating
1 Packing Appearance Internal Pallets/Cartons/Labels/Inserts/Bar Codes match customer order in quality and quantity, with neat appearance. Pass Better
2 Product Appearance Internal Material must match customer order.
No print film folding, no rough bevel, no bevel with white line, no film scratch or breakage, no color difference, no wear layer bubbles, no impurities, no stains, no dents, no scratches, no broken corners, no fish eyes, no trash, no holes, no hair/ foreign subject, no overhang or uneven backpad, etc. 		Pass Better
3 Dimensions Length ASTM F1700 ± 0.40 mm 0.03mm Best
Width ± 0.10 mm 0.02mm Best
4 Overall Thickness ASTM F1700 ± 0.10 mm 0.02mm Best
5 Squareness Length ISO 24342 ≤ 0.25 mm 0.03mm Best
Width ≤ 0.25 mm 0.02mm Best
6 Straightness Length ISO 24342 ≤ 0.25 mm 0.05mm Best
Width ≤ 0.25 mm 0.01mm Best
7 Stitching Gap (mm) EN13329 ≤ 0.10mm 0.02mm Best
8 Height Difference EN13329 ≤ 0.10mm 0.03mm Best
9 Wear Layer
Thickness		 EN 429 ± 0.02 mm 0.01mm Best
10 Resilient floor covering Determination of peel resistance EN ISO 24345:2012 ≥54N/50mm Longitudinal direction:91.3N/50mm
Cross direction:91.3N/50mm		 Best
11 Scratch Resistance EN 16094B > 2500g 3,800g Best
12 Micro-Scratch
Resistance (A & B)		 EN 16094 MSR-B1 - B3 MSR-B1 Best
13 Coating Adhesion
(Cross hatch)		 EN 16094B 5B 5B Best
14 GreenGuard Gold Certified UL 2818 - 2013
Gold Standard for Chemical Emissions for Building Materials, Finishes and Furnishings		 Refer to Standards Pass Best
15 Floorscore Certification SCS-EC10.3-2014v3.0 Refer to Standards Pass Best
16 CE Certification EN14041 Refer to Standards Pass Best
17 Fire resistance EN 9239-1
EN ISO11925-2
EN 13501-1		 Critical Fluxf≥8.0kW/m2
Fs≤150mm within 20s
Smoke≤750% minutes		 Bfl-S1 Better
18 Phthalate tests
(DBP/BBP/DEHP/DINP/DNOP/DIDP)		 EN 14372:2004 N/A Free Best
19 Dimension stability EN ISO23999:2012 ≦0.25% Manufacturing direction:-0.04%
Across-manufacturing direction:-0.01%		 Best
20 Seam strength EN 684:1995 N/A Ave.:360N/50mm Pass
Min.:330N/50mm		 Best
21 Residual indentation (%) ISO24343-1:2007 Average value≦8
Individual value≦10		 0.19 Pass Best
22 Resistance to chemicals ASTM F1700-13a &
ASTM F925-13		 No more than a slight change in
surface dulling, surface attack,or staining		 No change in surface dulling,surface attack,or staining was detected Best
23 Heat stability ASTM F1514-03(R2013) △E*ab< 8 △E*ab=0.67 Pass Better
24 Static loading ASTM F970-17 N/A 0.04mm Pass Better
25 Soluble heavy metal contents test EN71-3:2019 N/A Free Best
26 Large ball impact resistance NALFA/ANSI LF-01-2011 N/A No cracks or fractures occurred at the height of 2500mm Best
27 Static Electrical Propensity EN 1815:2016 method A ≦2kV 0.5kV Best
28 Airborne Sound Transmission
Loss Test and Class		 ASTM E90-23
ASTM E413-22		 N/A STC = 68 Best
29 Determination of Impact
Sound Insulation Class		 ASTM E492-22
ASTM E989-21		 N/A IIC = 67 Best
30 Formaldehyde EN 13986:2004+A1:2015 N/A Free Best
31 Surface Bond NALFA/ANSI LF-01-2011 N/A 1.14MPa Pass Best
32 Castor chair Resistance(25000 Cycles) NALFA/ANSI LF-01-2011
ISO4918:2016		 N/A No damage was found after test Best
33 Thermal conductivity EN 12664:2001 N/A 0.122 W/(m.K) Good
34 Thermal Resistance EN 12664:2001 N/A 0.054(m2.K)/W Good
35 Colour Fastness EN ISO 105-B02:2014 N/A ≥Grade 6 Good
36 Curling ISO 23999:2012 N/A Average: 0.1mm Pass Better
37 Locking strength ISO 10582:2017 Annex D Class 32, type I:≥1.5kN/m Long side(X): 6.8 kN/m
Short side(Y): 6.8 kN/m Pass		 Good
38 Resistance to staining EN423:2002 N/A Index 0: Not affected Pass Best
39 Slip resistance
(oil-wet ramp test)		 DIN 51130:2014 N/A Critical angle of inclination: 10.8°Classification: R10 Pass Good
40 Resistance to bacteria ISO 846-2019 Method C N/A Assessment of bacteria growth: 0 Pass Best
