(WG) - Generic WPC Engineered Vinyl Running Line
8.0mm 20mil
Specifications Technical Data
Length 60" Width 8.98"
Thickness 8mm Wear Layer 20mil
Finishing Handscrapped Emboss / Random EIR Edge Description Painted Bevel
Sqft/Box 29.92 lb/Box 43.8
Box/Plt 44 Sqft/Plt 1317
lb/Plt 1994 Plt/FTL 22
Limited
Residential Warranty
Lifetime Limited
Commercial Warranty
15Years
Characteristics Standards Requirements Result
TUV Premium
Certification
Belgian VOC regulation
BREEAM Exemplary Level
Refer to Standards Pass
CE Certification EN14041 Refer to Standards Pass
Floorscore
Certification
SCS-EC10.3-2014v3.0 Refer to Standards Pass
Castor Chair Resistance NALFA LF 01-2011 Section 3.9 N/A After 25000 cycles,test specimens no visible damage
Dimensional Stability ASTM F2199-09(2014)
Heating temperature:65oC
≤0.25% MD:=-0.092%
AMD:=-0.030%
Pentachlorophenol(PCP) With reference to
PD CEN/TR 14823:2003
N/A Free
Formaldehyde Emission EN 717-1:2004 E1≤0.124mg/m³ Free
Fire resistance EN ISO 9239-1
EN ISO 11925-2
EN 13501-1:2010
N/A Bfl-S2
Calculated Sound
Transmission(STC)
ASTM E90-23
ASTM E413-22
No pass-fail criteria STC=68
Impact Sound
Reduction(IIC)
ASTM E492-22
ASTM E989-21
No pass-fail criteria IIC=68
Impact resistance ASTM F1265-03a(2013) N/A No crack
Phthalate tests
(DBP/BBP/DEHP/DINP/
DNOP/DIDP)
REACH NO.1907/2006 N/A Free
Resistance to Heat ASTM F1514-03(2013) △E* shall not greater than 8.0 after7 days exposure to 70°C △E*=0.66
Residual indentation ASTM F1914-07(2011) Average≤8% Max≤10% Average≤6.6% Max≤7.4%
Slip resistance EN 13893:2003 EN 14041:μ≥0.3 μ=0.36
Class DS
Density ASTM D792-13 Method A,Water at 23°C N/A 1.15g/cm³
Squareness ASTM F2055-17 ≤0.25mm/305mm Pass
Size ASTM F2055-17 A tolerance of ±0.4mm/305mm Pass
Thickness ASTM F386-17 A tolerance of ±0.13mm Pass
Thermal Conductivity ASTM C518-10 N/A 0.114 W/(m.K)
Thermal Resistance ASTM C518-10 N/A 0.062(m².K)/W
